PRECISION SEEDER

The BCC Precision Seeder was developed to meet the following main criteria:

– High production capacity
– High accuracy sowing
– Handling of a variety of seed species with different sizes and shapes
– High reliability
– Low maintenance

Highest possible seeding accuracy can be achieved by the BCC Precision Seeder. Typically nurseries using the Precision Seeder
reach accuracy rates of more than 95%. However, seeding accuracy of more than 98% is generally achieved with seedlots that have been sized and graded correctly prior to seeding.

SPECIFICATIONS

Item Code: PRSE

Dimensions (L x W x H) mm:
770 x 600 x 1620 (depending on height of conveyor belt)

Weight: 65kg

Power supply:
3 x400V, 50Hz, 5Amp

Compressed air consumption:
100 litres/minute at 600kPa (6Bar)

Maximum production capacity (approx.): HIKO: 20 trays/minute
Plantek & SideSlit: 13-18 trays/minute
96 Insert Frame: 10 trays/minute
