Liquid Separation is used as a continuous process for separation of mechanically damaged seed, seeds with insect damages, resin particles and other particles that resemble the seeds in size and form, but have a dissimilar relative density. A washing effect is also achieved, as dust and wing particles stuck to the seed are removed. Liquid
separation is an efficient method for many species and seed lots, although this process is not always required after seed extraction.
The Liquid Separator is commonly used in small to large scale seed processing plants where seed requires a liquid separation process.
Dimensions (L x W x H):
3800mm x 2000mm x 2500mm
(incl. seed hopper)
Power supply: 3 x 400V, 50Hz
Power requirement: <0.50 kW
Design capacity: 10 – 50 kg seed/hour
Volume of seed hopper: 100 liters
Total water volume: 200 liters
20-50 liters/minute at 10-30°C
(adjustable temperature is preferred)
Construction: Stainless separation tank and bottom tank with pump and pipes for water circulation.
